Industrial Heavy Duty Metal Longspan Shelving

The medium duty longspan rack with safety and reliable type, and easy to install. It can be single use or match with various shelf. The loading capacity for each shelf is about 700kg and the pitch adjusted at 50mm.

All of our Longspan Racking has been pre-surface treatment process to rust-proof, finished by automatic powder electrostatic coating, make sure the surface is smooth.

The structure of the medium duty longspan rack is divided into: Uprights, cross braces, diagonal braces, P-Beams, and Wire Mesh Decking.

Longspan Shelving Specification(MM)

Uprights	Spec	Thickness	Cross Section
	55*47	1.5
		2.0
P-Beam	50*30	1.2
	60*40
	80*50	1.5
Cross Brace	30*15	1.2
Back Cross Brace
Panel		0.6
		0.7
		0.8
		1.0
